ValidTi PRO Series: The Zero-Stress Standard
Engineered to eliminate 'Memory Effect' in large-span screw-retained frameworks.
Application Notice
DENTAL CAD/CAM FEEDSTOCK. Not for industrial stamping or general sheet metal applications.
Technical Specifications
| Property | ValidTi PRO (Annealed) | Standard Raw Ti (Cold Rolled) | Impact on Milling |
|---|---|---|---|
| Oxygen (O) Content | < 0.10% | ~ 0.13% | High Toughness; Prevents Fatigue Failure |
| Iron (Fe) Content | < 0.12% | ~ 0.25% | Superior Biocompatibility & Uniformity |
| Raw Material Source | Grade 0A Virgin Sponge | Standard Sponge (Scrap mix) | Aerospace Grade Input; Zero Inclusions |
| Residual Stress | Negligible | High | Causes warping upon material removal |
| Elongation | > 12% | 8-10% | Prevents micro-cracks during high-load chewing |
| Hardness (HV) | 310 HV | 340+ HV | Extended bur life (Softer matrix) |
Framework Distortion (Warping)
Risk Addressed
Framework Distortion (Warping)
Milling removes up to 80% of the disc volume. In standard discs, this release of mass unbalances internal stress vectors, causing the 'spring-back' effect. ValidTi PRO undergoes a 12-hour proprietary vacuum annealing cycle to neutralize these vectors before the disc ever reaches your mill.
Fig 1. The ValidTi Triple-Annealing Cycle aimed at neutralizing internal grain stress. Technical line graph showing Temperature vs Time with annotations.
Compliance & Traceability
Access Heat Treatment Logs
